Example 7. 3270 Emulation over a TCP/IP Network via an AnyNet SNA/IP Gateway to a VTAM Host on an APPN Network

REQTEXT — Figure 1. 3270 Emulation over a TCP/IP Network via an AnyNet® SNA/IP Gateway to a VTAM® Host on an APPN® Network

Follow these steps to establish communication between the Windows® Server 2008 workstation (Node B) and the Windows® 2000 workstation (Node C).

For Windows® Server 2008 Node B, add the following entries to the HOSTS file:

        192.168.1.2 CP2.NETA.SNA.IBM.COM
        127.0.0.2   DEPLU1.NETA.SNA.IBM.COM
        192.168.1.2 DEPLU1.NETA.SNA.IBM.COM

For Windows® 8, Windows® 8.1, or Windows® 10 Node C, do as follows:

Add the following entry to the local HOSTS file:

        192.168.1.1 CP1.NETA.SNA.IBM.COM

Create a workstation profile using the Personal Communications configuration tool:
2. Click the Start/Configure Session icon; or click Configure from the Communication menu. The Customize Communication window is displayed.
3. Select the following options:
  - Host: zSeries™
  - Interface: AnyNet®
  - Attachment: TCP/IP LU 0,1,2,3 via DLUR
4. Click Configure.
5. Click Configure Link.
6. On the Configure Local System window, enter:
  PC Location Name: NETA.CP2
7. On the Configure DLUR window, enter:
  - DLUS name: NETA.CP1
  - Routing Preference: Nonnative only
8. On the Configure AnyNet® Connection window, enter:
  SNA domain name suffix: SNA.IBM.COM
9. Save your workstation profile.
