Example 3. APPC3270 Emulation over a TCP/IP Network

Follow these steps to establish communication between the VTAM® host (Node A) and the Windows® 2008 workstation (Node B).

For VTAM® Node A, add the following entry to the local HOSTS file:

10.2.1.2  LUNAME2.NETA.SNA.IBM.COM

For Windows® 2003 Node B, do as follows:

Add the following entry to the local HOSTS file:
```
     10.1.1.1  LUNAME1.NETA.SNA.IBM.COM
```
Create a workstation profile using the Personal Communications configuration tool:
1. Click the Start/Configure Session icon; or click Configure from the Communication menu. The Customize Communication window is displayed.
2. Select the following options:
  - Host: zSeries™
  - Interface: AnyNet®
  - Attachment: APPC3270
3. Click Configure.
4. Click Configure Link.
5. On the Configure Local System window, enter:
  PC Location Name: NETA.LUNAME2
6. On the Configure Logical Connection window, enter:
  - System location name: NETA.LUNAME1
  - Routing Preference: Nonnative only
7. On the Configure AnyNet® Connection window, enter:
  SNA domain name suffix: SNA.IBM.COM
8. Save your workstation profile.
